GTO
Front disc brakes are available to further enhance good braking system .... 3-speed Turbo Hydra-Matic is quick and smooth... 400-cubic- inch V-8 performance equals – or beats – last year’s 389 and offers more power potential... ’67 is quieter inside, displays better quality.

how the car performed...
ACCELERATION
            (2 aboard) 4-speed      3-speed
                                                 Hydro
0-30 mph .............. 2.0 secs.        2.0
0-45 mph .............. 4.0 secs.        4.1
0-60 mph .............. 4.9 secs.        5.2
0-75 mph .............. 6.6 secs.        6.8

TIME AND DISTANCE 10 ATTAIN PASSING SPEEDS:
40-60 mph .. 2.1 secs., 153.7 ft.;
                   2.0 secs., 146 ft.
50-70 mph .. 2.0 secs., 176 ft.;
                   2.0 secs., 176 ft.

STANDING START QUARTER-MILE:
(M&H drag tires)
13.09 secs., 106.5 mph;
13.38 secs., 105 mph
(Std. tires)
14.21 secs., 102.97 mph;
14.09 secs.,101 mph

SPEEDS IN GEARS    @   SHIFT POINTS:          4-spd    rpm    3-speed       Hydro rpm
1st    49 mph  5500   1st   43 mph    5500
2nd   60 mph  5500   2nd   43 mph    5500
3rd    89 mph  5500   3rd  107 mph    5500
4th  107 mph  5500
MPH PER 1000 RPM: 19.4 mph – both cars

SPEEDOMETER ERROR:
Electric Speedometer ...    30 45 50 60 70 80
Car Speedometer (4-spd) ..30 45 50 61 71 80 (auto.) .............                31 46 52 61 71 81

STOPPING DISTANCES: (Front discs)
from 30 mph, 34 ft.; from 60 mph, 186 ft. (Drum brakes) from 30 mph, 35 ft.; from 60 mph, 169 ft.

specifications...
ENGINE: Ohv V-8 (both cars) Bore and stroke (ins.): 4.12 x 3.75 Displacement (cu. ins.): 400 Horsepower: 360 On 5400 rpm Max. torque (lbs.-ft.): 438 @ 3800 Compression ratio: 10.75:1 Carburetion: 1 4-bbl. Quadrajet; force-fed air from hood scoops TRANSMISSION: (stick) Manual 4-speed, close-ratio 2.20:1 low gear; aluminum case; floor-mounted Hurst shifter. (Auto.) 3-speed torque converter Turbo Hydra-Matic; low-gear ratio 2.48:1, with total torque multiplication of 5.70:1 at start. Steering-column-mounted lever standard, floor- console-mounted shifter optional. FINAL DRIVE RATIO: 3.90:1 (both cars) SUSPENSION: (both cars) Front – independent with upper and lower control arms and coil springs. Tubular shock absorbers. Heavy-duty standard. Rear – heavy-duty 1-piece rear axle assembly with coil springs and 4-link pivoted control arm loca- tion. Super-lift (air-filled) tubular shock absorbers. STEERING: Recirculating ball bearing, coaxial power assist. Gear ratio 17.5:1, overall ratio 22.0:l. Turning diameter: 40.9 ft., curb-to-curb. Turns lock-to-lock: 4.2. WHEELS: (std. type) Disc-steel, 5-lug, 14 x 6 ins. TIRES: F70 x 14 Wide-Oval, 4-ply rated, synthetic fiber construction. BRAKES: Dual-system hydraulic, internal expanding drum-type standard; power-assisted front discs optional. Front disc – 11.12 ins. dia. Front drum: 9.5-in.-dia. x 2.5-in.-wide. Rear drum: 9.5-in.-dia. x 2.0-in.-wide. Effective lining area (drum brakes), 149.4 sq. ins.; (discs), 101.9 sq. ins. FUEL CAPACITY: 21.5 gals. BODY & FRAME: Perimeter-type frame with swept hips. Separate construction body. DIMENSIONS: Wheelbase: 115 ins. Track: front, 58 ins.; rear, 59 ins. Overall length 206.6 ins, width 74.7 ins., height, 53.7 ins. Trunk 21.1 cu. ft. CURB WEIGHT: Stick, 3445 lbs.; Automatic, 3490 lbs.

prices and accessories...

MANUFACTURER’S SUGGESTED RETAIL: (excludes state and local taxes, license, options, accessories, and transportation, but includes Federal excise tax and PCV device) Sport coupe $2935; Convertible $3165. (335-hp V-S, 3-spd trans, – std.)
OPTIONS AND ACCESSORIES:
360-hp engine ...................................76.89 Ram-Air (avail. only on 360 engine) .........263.30 Capacitor discharge ignition ............ 104.26 Turbo Hydra-Matic .......................... 226.44 Floor console with Hurst shifter ......... 68.40
4-speed transmisqion ......................184.31 Limited-slip differential/H-D rear end ... 63.19 Hood-mounted tach with Rally Cluster. 84.26 Power front Disc Brakes .................. 104.79 Superlift shock absorbers (air-filled) ..... 39.50 Heavy-duty battery .............................. 3.48
Rally I and Rally II wheels (set) ........... 56.86 Pushbutton AM radio ......................... 61.09 Wood-grain steering wheel ................. 30.02

continued

and optional with Turbo Hydra-Matic. The 4-speed linkage is firm, has a close gate, and appeared strong enough to survive manipulation by Paul Bunyan. The 4-speed car ran consistently in the 13.10 to 13.20-second area with speeds usually around 106 mph. This car re- corded one of the fastest 0-60 mph times we’ve ever seen – 4.9 seconds – but with the M&H tires on the back, it’s really not a fair comparison with our other road tests. After a dozen or more runs, we had trouble with both cars plain quitting toward the end of the quarter. We fi- nally traced this to low fuel tanks, with the cure being simply to run with over a quarter-tank of gas at all times. This test of the ’67 GTO was one of the most comp- rehensive we’ve ever done. We had the opportunity to drive several different varieties, and in many different conditions. We ran quite a few mileage checks and averaged 13.5 mpg on the open highway with a 3.90: 1 rear axle ratio, and 11.5 around town. The fit and finish on all the cars was the best we’ve scen on any Pontiac GTO, and we’d rate the driveability as excellent for enthusiasts as well as commuters. They’re housebroken Tigers, but they can revert to the jungle whenever you give the word. /MT
